KVP04-1.1-24 Mini Brushless Ink Circulation Pump
SKU:
Ink Pump - 041
- $75.20
- $75.20
- Unit price
- per
For any product questions, click the Contact button to reach us directly.
Secure payments
Every payment you make on iColorPro is secured with strict SSL encryption and PCI DSS data protection protocols
Standard refund policy
Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Description
xThe KVP04-1.1-24 is a miniature diaphragm ink pump developed for compact digital printing equipment requiring stable vacuum and precise ink flow control. Its brushless motor design ensures long service life and low operating noise, even under continuous working conditions.
With a flow capacity of up to 1.1L/min and reliable negative pressure output, this pump supports efficient ink circulation, air extraction, and pressure balancing in inkjet and coding systems. The compact housing allows easy installation in space-limited equipment.
The EPDM diaphragm structure provides strong resistance against UV, solvent, and water-based inks. Clear inlet and outlet labeling simplifies system integration and reduces installation errors.
Performance Advantages
- Brushless motor for extended lifespan and low maintenance
- Stable vacuum output for ink recovery applications
- High chemical resistance with EPDM diaphragm
- Low vibration and quiet operation
- Compact structure suitable for precision equipment
Product Parameters
| Model | KVP04-1.1-24 |
| Voltage | DC 24V |
| Max Flow | 1.1 L/min |
| Motor | Brushless DC |
| Negative Pressure | ≥ -0.04 MPa |
| Positive Pressure | ≥ 0.09 MPa |
| Application | Inkjet printers, coding systems, UV equipment |
This pump is recommended for users seeking a compact, durable, and low-noise solution for ink circulation and vacuum control in professional printing systems.
